Spec Sheet - Docking Drawer Blade and Docking Drawer Blade Duo

Docking Drawer Blade and Docking Drawer Blade Duo


Here are the key specifications for a Docking Drawer Blade and Docking Drawer Blade Duo side by side.

Docking Drawer Blade

Docking Drawer Blade Duo

Part Numbers


0290-30002

2 AC & 2 USB-C (PD)


0290-30000

2 AC & 2 USB-A


0290-30001

4 USB-A

Part Numbers


0290-30102

2 AC, 2 USB-C (PD) & 4 USB-A


0290-30100

2 AC & 6 USB-A


0290-30101

8 USB-A


0290-30402

4 AC & 4 USB-C (PD)


0290-30400

4 AC & 4 USB-A

Made in Mexico

Made in Mexico

Resources


  1. Mounting Diagrams
  2. DXF and STEP Files
  3. 3D Animation
  4. Electrical Planning Guide
  5. Installation Manual
  6. Cutout Template

Literature

  1. Docking Drawer Literature
